The image shows a gray, rectangular tray with four compartments. The compartments are evenly distributed, and the tray has a smooth surface. The dimensions are given in millimeters.
Vacuum-formed insert T-298 553 x 353 x 55 mm, 6 compartments
(Product No.: 032.T-298)
The image shows a gray, rectangular tray with four compartments. The compartments are evenly distributed, and the tray has a smooth surface. The dimensions are given in millimeters.
Notice / Inquire

Vacuum-formed insert T-298 553 x 353 x 55 mm, 6 compartments

dpvlink:
18944
Length :
553 mm
Width :
353 mm
Height :
55 mm
Properties:
Further product information
Imprinting / Printing for boxes
configure_now


Minimum order:
10 PCE
24.10 CHF

excl. 8.1% tax

10 PCE
Compare Compare
Notice / Inquire
Product Info

Vacuum-formed insert T-298 553 x 353 x 55 mm, 6 compartments

The deep-drawing insert T-298 from Licefa is specifically designed for the protection and storage of sensitive electronic components. This insert features six compartments measuring 238x102x52 mm, ideally sized for standardized containers of 600x400 mm.
The insert is made of Liastat, an electrically conductive material that meets the standards of DIN EN 61340-5-1 and provides a surface resistance between 10^3 and 10^5 Ohm. The dimensions of the deep-drawing insert are 553 mm in length, 353 mm in width, and 55 mm in height, allowing for compact and efficient use of storage space.
Additionally, the insert is equipped with a handle recess, which facilitates handling, and it supports stackable turning, simplifying storage and transport. The combination of functionality and protection makes the deep-drawing insert T-298 an optimal solution for technical purchasers who value the safety and organization of their electronic components.
Length
Length
553 mm
Width
Width
353 mm
Height
Height
55 mm
Conductivity
Conductivity
conductive
Surface resistance Rs
Surface resistance Rs
103 - 105 Ω
Cavities
Cavities
6
Dimensions cavities
Dimensions cavities
238x102x52 mm
Suitable for containers
Suitable for containers
600x400 mm
Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 318
Complete Catalog 2023 - 2024
Configurators:
Imprinting / Printing for boxes

Product Family

Vacuum-formed inserts T-298

Article image
Article description
Length
Width
Height
Price
Compare
032.T-298 - Vacuum-formed insert T-298 553 x 353 x 55 mm, 6 compartments
032.T-298
Vacuum-formed insert T-298 553 x 353 x 55 mm, 6 compartments
553 mm
353 mm
55 mm
24.10 CHF
