The image shows a soldering iron. It has a long handle, a metallic tip, and two switches. A cable spirals from the tip to the end of the handle.
DLV-7321-BKE Electric screwdriver ESD
(Product No.: 461.300)
The image shows a soldering iron. It has a long handle, a metallic tip, and two switches. A cable spirals from the tip to the end of the handle.
Notice / Inquire

DLV-7321-BKE Electric screwdriver ESD

dpvlink:
3431
Torque range:
0.05 - 0.49 Nm
Idle speed High:
1000
Idle speed Low:
700
Start type:
lever start
Properties:
Further product information

572.20 CHF

excl. 8.1% tax

1 PCE
Compare Compare
Notice / Inquire
Product Info

DLV-7321-BKE Electric screwdriver ESD

The DLV-7321-BKE ESD electric screwdriver from delvo is specifically designed for precise assembly tasks where ESD safety and accurate torque control are required. This model features a lever start and is supplied without a control unit. The control of the electric screwdriver is managed via an external control unit, which allows for speed preselection and a soft-start regulation. The screwdriver starts progressively, meaning that the rotation begins slowly and automatically increases to prevent damage to sensitive screw heads.
Technically, the DLV-7321-BKE offers a continuously adjustable speed from 700 to 1000 RPM and a torque of 0.05 to 0.49 Nm. The repeatability is at 3%. The electric screwdriver has a length of 215 mm, a grip diameter of 32 mm, and weighs 350 g. It operates with a voltage of 36 VDC and a power of 26 W. The tool holder is designed for 1/4" hex bits.
The DLV-7321-BKE is ideal for applications where precision and protection against electrostatic discharge are required.
Torque range
Torque range
0.05 - 0.49 Nm
Idle speed High
Idle speed High
1000
Idle speed Low
Idle speed Low
700
Start type
Start type
lever start
Output voltage DC
Output voltage DC
36 V/DC
Power
Power
26 W
Handle length
Handle length
32 mm
Length
Length
215 mm
ESD
ESD
yes
suitable bit type
suitable bit type
Type B E6.3
Accuracy
Accuracy
3 %
Bit type
Bit type
Hexagon 6.35
Screw size self-tapping
Screw size self-tapping
1.2- 2.6 mm
Screw size thread screw
Screw size thread screw
1.0- 3.0 mm
Socket
Socket
1/4" 6.35 mm
Torque setting
Torque setting
stepless
Weight
Weight
350 g
Show accessories
Pictograms
ESD protective
Electrostatic Discharge - marking for materials intended to protect other components from ESD by avoiding potential differences.

Accessories

Accessories

The image displays a rectangular device with a golden top and a black front. It features two large knobs for "Speed" and "Soft Start," as well as a power switch and a small red light indicator.
Control unit for series DLV7300-BK
DLC-1213 control unit (230 VAC / 36 VDC),
with soft start and speed preselection
Serial number...
(for DLV 7321 / 7325 / 7331 / 7335)
dpvlink
25701

255.00 CHF
Show product
Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 445
Complete Catalog 2023 - 2024

Product Family

Delvo Electric screwdriver

The DLV-7321-BKE and DLV-7331-BKE electric screwdrivers are suitable for particularly precise assembly work in a range from 1 mm to 3.5 mm. The electric screwdrivers are controlled via a separate control unit with speed preselection and soft-start control.

The DLV-7321-BKE and DLV-7331-BKE start progressively, i.e. the rotation starts slowly and increases automatically. This means that even damage to sensitive screw heads is largely avoided.

Technical data screwdriver:

Length / handle:215 mm / 32 mm
Weight:350 g
Voltage / output:36 VDC / 26 W
Speed:
DLV 7321steplessly 700-1000 rpm
DLV 7331steplessly 500-700 rpm
Torque setting range:
DLV 7321steplessly 0.05 - 0.49 nm
DLV 7331steplessly 0.29 - 1.18 nm
Repeat accuracy:3 %
Tool holder:

type B E6.3 (1/4" / 6.35mm)


Article image
Article description
ESD
Torque range
Idle speed High
Idle speed Low
Start type
Price
Compare
461.300 - DLV-7321-BKE Electric screwdriver ESD
461.300
DLV-7321-BKE Electric screwdriver ESD
0.05 - 0.49 Nm
1000
700
lever start
572.20 CHF
461.310 - DLV-7331-BKE Electric screwdriver ESD
461.310
DLV-7331-BKE Electric screwdriver ESD
0.29 - 1.18 Nm
700
500
lever start
618.55 CHF
