The image shows a simplified drawing of a fountain pen. In the center, there is a number "8" visible, surrounded by a stylized body and a pointed nib.
Suction nozzle DX 118
(Product No.: 513.148.99)
The image shows a simplified drawing of a fountain pen. In the center, there is a number "8" visible, surrounded by a stylized body and a pointed nib.
Notice / Inquire

Suction nozzle DX 118

dpvlink:
6867
External Ø:
1.5 mm
Internal Ø:
0.7 mm
Length :
23 mm
Further product information

10.85 CHF

excl. 8.1% tax

1 PCE
Compare Compare
Notice / Inquire
Product Info

Suction nozzle DX 118

The suction nozzle DX 118 from Weller is a highly specialized accessory for the desoldering stations DSX 80 and DSXV 80, designed for precise and efficient extraction of molten solder. Made from heat-resistant materials, this nozzle is excellent for use in repair, prototyping, and manufacturing processes in the electronics sector. With an inner diameter opening of 0.7 mm, an outer diameter of 1.5 mm, and a length of 23 mm, it enables optimal handling and functionality. Available in various sizes and shapes, it offers flexible application possibilities according to the specific requirements of the application.
The test number 8 guarantees compliance with high quality standards, essential for professional applications.
External Ø
External Ø
1.5 mm
Internal Ø
Internal Ø
0.7 mm
Length
Length
23 mm
Test No.
Test No.
8
Documents

Downloads

Please log in to download datasheets! :
There are several datasheets for this product. Please log in!

Catalogues

Page: 617
Complete Catalog 2023 - 2024

Product Family

Weller Suction nozzles eccentric fastening for DSX 80, DSXV 80

The DX suction nozzles are designed for the DSX 80 and DSXV 80 desoldering irons and are ideal for removing solder from a wide variety of solder joints. They heat up, melt the solder and suck it out through an integrated tube into the tin collection container when the vacuum is activated.


Article image
Article description
ESD
External Ø
Internal Ø
Length
Test No.
Price
Compare
513.140.99 - Suction nozzle DX 110
513.140.99
Suction nozzle DX 110
1.9 mm
0.7 mm
23 mm

10.85 CHF
513.141.99 - Suction nozzle DX 111
513.141.99
Suction nozzle DX 111
2.5 mm
0.7 mm
23 mm
1
10.85 CHF
513.142.99 - Suction nozzle DX 112
513.142.99
Suction nozzle DX 112
2.3 mm
1.0 mm
23 mm
2
10.85 CHF
513.143.99 - Suction nozzle DX 113
513.143.99
Suction nozzle DX 113
2.5 mm
1.2 mm
23 mm
3
10.85 CHF
513.150.99 - Suction nozzle DX 113HM
513.150.99
Suction nozzle DX 113HM
2.5 mm
1.2 mm
23 mm
3
13.80 CHF
513.144.99 - Suction nozzle DX 114
513.144.99
Suction nozzle DX 114
3.3 mm
1.8 mm
23 mm
4
10.85 CHF
513.145.99 - Suction nozzle DX 115
513.145.99
Suction nozzle DX 115
1.9 mm
0.7 mm
23 mm
5
10.85 CHF
513.146.99 - Suction nozzle DX 116
513.146.99
Suction nozzle DX 116
2.7 mm
1.2 mm
29 mm
6
10.85 CHF
513.147.99 - Suction nozzle DX 117
513.147.99
Suction nozzle DX 117
2.7 mm
0.7 mm
23 mm
7
10.85 CHF
513.148.99 - Suction nozzle DX 118
513.148.99
Suction nozzle DX 118
1.5 mm
0.7 mm
23 mm
8
10.85 CHF
513.151.99 - Suction nozzle DX 119
513.151.99
Suction nozzle DX 119
1.1 mm
0.7 mm
31 mm
9
10.85 CHF
513.152.99 - Suction nozzle DX 120
513.152.99
Suction nozzle DX 120
2.5 mm
1.1 mm
22 mm

10.85 CHF
513.153.99 - Measuring nozzle
513.153.99
Measuring nozzle
3.3 mm
0.55 mm
21.5 mm

19.15 CHF
587.067.94 - Cone insert cleaning tool
587.067.94
Cone insert cleaning tool




23.80 CHF
513.790.99 - Suction nozzles set DX 110 - 115 DX
513.790.99
Suction nozzles set DX 110 - 115 DX




67.40 CHF
