Bye bye CORSTATTM, Bye bye CORTRONIC® – Hello CORpro TRONIC®

Farewell with an outlook: prepared for future requirements according to DIN EN & IEC

The classics CORTRONIC® and CORSTAT™ will be discontinued by our supplier HANS KOLB Wellpappe on 30.09.2025 and 31.12.2025 respectively.

But don't worry: with CORproTRONIC® , the high-performance successor is already available. HANS KOLB is gradually changing its product range - we are accompanying this process and ensuring that you continue to receive the right solution.

Our stock will be adjusted accordingly. If you have any questions about the changeover or specific items, our sales team will be happy to help you at any time.

The benefits of CORproTRONIC®

  • Highest ESD protection
  • Fulfills future standards
  • Stable, sustainable & reusable

Do you need more details? In the following table we have compared the most important features for you - so that you can see directly why CORproTRONIC® is the future.

Technical data (all measured values given are typical values and properties)

Corstat™

Cortronic®

Dissipativ

CORproTRONIC®

Electric
Surface resistance:
Shielding layer Ohm/sq
< 10 4
< 10 2
< 10 4
Leakage layer Ohm/sq.
10 5-6
10 7-8
10 7-9
10 7-9
Waste time
< 1 sec.
< 1 sec.
< 2 sec.
< 1 sec.
Frictional electricity
none
none
none
none
Surfaces
black
blue/standard
black/blue
AD black/ID blue
Energy Bag Test
<50 nJ
<15 nJ
No shielding
<10 nJ
Chemical
Corrosion
none
none
none
none
Galvanic reaction
none
none
none
none
Recyclable
Resy 0062
PAP20
Resy 0062
PAP20
Resy 0062
PAP20
Resy 0062
PAP20
Mechanical
Ausgangsmaterial-Decken
Kraftliner + replacement papers
Kraftliner + replacement papers
Kraftliner + replacement papers
Kraftliner + replacement papers
Abrasion resistance
good
good
good
good
Printability
limited
good
limited
limited
Specifications
Corresponds to
ANSI/ESD S541
ANSI/ESD S541
ANSI/ESD S541
ANSI/ESD S541
Corresponds to
DIN EN 61340-5-3
(bis 01.04.2025)
DIN EN 61340-5-3
DIN EN 61340-5-3
DIN EN 61340-5-3

Not subject to the RoHS directives (2002/95/EC and 2002/96/EC)
